    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Ask Lasest Price
    Brand Name : BAXIT
    Model Number : BXT-HMS-03B/05B/09B/12B/20B/30B/40B/50B/60B
    Price : US$3587-12238/unit
    Payment Terms : L/C,D/A,D/P,T/T,Western Union
    Supply Ability : 10000pcs
    Delivery Time : 5-8Working day
    • Product Details
    • Company Profile

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Computer room precision air conditioner


    The computer room air conditioner (CRAC) is a special type of air conditioner specifically designed for computer rooms, data centers, communication base stations, etc., where high concentrations of electronic equipment are present. Its core function is to provide a stable temperature and humidity environment, high cleanliness air, and reliable continuous operation guarantee for the equipment, in order to ensure the stable performance, extended lifespan, and data security of the electronic devices.

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center


    The temperature adjustment range is 16 - 30°C. The humidity control range can be freely adjusted from RH 30% to 95%, with a humidity control accuracy of ±3% RH, and a temperature accuracy of ±1°C. It features more reliable performance and more flexible functions.

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    ModelBXT-HMS-03BBXT-HMS-05BBXT-HMS-09BBXT-HMS-12B
    Refrigeration(kw)3.559.212
    Heating(kw)23.557
    Dehumidification(kg/h)23710
    Horsepower(P)1.5235
    Circulating air volume(m³/h)550100022003000
    Applicable area: ㎡
    Floor height: 3 meters
    10﹣1515﹣2525﹣3535﹣55
    Power supply(V)220V50Hz220V50Hz380V50Hz380V50Hz
    Total capacity of the unit group(kw)57.211.215.5
    Indoor Unit Size(mm)
    L*W* H
    800*480*1825800*480*1825960*580*2025960*580*2025
    outdoor unit Size(mm)
    L*W* H
    857*440*616857*440*6161093*456*8131193*456*963
    Connection pipe size(mm)High pressure9.529.529.529.52
    Low pressure12.712.712.712.7
    ControllerPLC Intelligent touch screen
    Temperature control range and accuracy18-30℃ Precision±1℃
    Humidity control range and accuracy50-70% Precision±5%RH(Customizable precision±2%RH)
    Refrigerant type(R22 R407C R410 R134a)Optional
    Refrigerant throttling methodThermostatic expansion valve
    Auxiliary electric heatingElectric heating type
    Humidifier formElectrode type / Electric heating type


    ModelBXT-HMS-20BBXT-HMS-30BBXT-HMS-40BBXT-HMS-50BBXT-HMS-60B
    Refrigeration(kw)2030405060
    Heating(kw)1218212832
    Dehumidification(kg/h)1320304050
    Horsepower(P)810162024
    Circulating air volume(m³/h)4200550080001000012000
    Applicable area: ㎡
    Floor height: 3 meters
    60﹣8080﹣120130﹣160160﹣200200﹣240
    Power supply(V)380V50Hz380V50Hz380V50Hz380V50Hz380V50Hz
    Total capacity of the unit group(kw)2235435365
    Indoor Unit Size(mm)
    L*W* H
    1222*742*18851502*952*19751652*952*19851652*952*20831820*952*2185
    outdoor unit Size(mm)
    L*W* H
    788*788*9251193*456*963788*788*925888*838*1085888*838*1085
    Connection pipe size(mm)High pressure169.52*216*219*219*2
    Low pressure1912.7*219*222*222*2
    ControllerPLC Intelligent touch screen
    Temperature control range and accuracy18-30℃ Precision±1℃
    Humidity control range and accuracy50-70% Precision±5%RH(Customizable precision±2%RH)
    Refrigerant type(R22 R407C R410 R134a)Optional
    Refrigerant throttling methodThermostatic expansion valve
    Auxiliary electric heatingElectric heating type
    Humidifier formElectrode type / Electric heating type

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Actual installation diagram

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Packing & Delivery

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    Company Profile

    Precision Environmental Close Control Air Conditioner Systems for Technological Room Server Room Data Center

    FAQ

    1. who are we?
    We are based in Shanghai, China, start from 2017,sell to North America(20.00%),Western Europe(15.00%),South America(10.00%),Oceania(10.00%),Northern Europe(10.00%),Eastern Europe(10.00%),South Asia(5.00%),Southern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 5-10 people in our office.

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you buy from us?
    Differential Scanning Calorimeter, Thermogravimetric Analyzer, Differential Thermal Analyzer, Oxygen Bomb Calorimeter, Spot Cooler

    4. why should you buy from us not from other suppliers?
    We have 10 years of experience in design and development. The price preferential benefit There is a lot of goods in stock The service is good

    5. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,DDU,Express Delivery,DAF;
    Accepted Payment Currency:USD;
    Accepted Payment Type: T/T,Credit Card,Western Union;
    Language Spoken:English,Chinese
