Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

Shanghai Glomro Industrial Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium from wholesalers

    Buy cheap Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium from wholesalers
    • Buy cheap Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium from wholesalers

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Ask Lasest Price
    Brand Name : BAXIT
    Model Number : BXT-DSF600/BXT-DSF900
    Price : US$17,805-18,780/unit
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 10000pcs
    Delivery Time : 5-8Working day
    • Product Details
    • Company Profile

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Full-spectrum direct reading spectrometer


    The full-spectrum direct reading spectrometer adopts international standard design and manufacturing techniques, and utilizes fully digital technology to replace the cumbersome photomultiplier tube (PMT) analog technology. It is in sync with international spectrometer technology and features a digital excitation light source, an international-level detector, and a high-speed data reading system, enabling the instrument to possess high performance, low detection limit, long-term stability, and repeatability.
    The spectrometer is one of the preferred devices for quality monitoring, material type identification, material research and development in the metal manufacturing, processing, and metallurgy industries.

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Technical Specifications

    ModelBXT-DSF600BXT-DSF900
    Detection MatrixIron-based, copper-based, aluminum-based, nylon-based, cobalt-based, magnesium-based, titanium-based, zinc-based, lead-based, etc.Iron-based, copper-based, aluminum-based, nylon-based, cobalt-based, magnesium-based, titanium-based, zinc-based, lead-based, etc.
    Testing timeDepending on the type of sample, it is generally around 25 secondsDepending on the type of sample, it is generally around 25 seconds
    Optical systemPaschen-Runge Rowland Circle Full-Spectrum Optical SystemPaschen-Runge Rowland Circle Full-Spectrum Optical System
    Wavelength range160-800nm130-800nm
    Focal length300mm400mm
    DetectorHigh-resolution multi-CMOS image sensorInternational-level detector module, high-performance linear CCD
    ElectrodeTungsten Jet ElectrodeTungsten Jet Electrode
    Analysis GapSample table analysis gap:3. 5mmSample table analysis gap:3.5mm
    Working temperature(10-35)℃(10-35)℃
    Storage temperature(0-45)℃(0-45)℃
    Work humidity20%-80%20%-80%
    Purity requirements for argon gas99.999%99.999%
    Argon gas inlet pressure0.5MPa0.5MPa
    In an argon flowExcitation flow rate is approximately 3. 5L/minExcitation flow rate is approximately 3.5L/min
    Light source typeNewly developed adjustable digital light source, high-energy pre-combustion technology (HEPS)Newly developed adjustable digital light source, high-energy pre-combustion technology (HEPS)
    Discharge frequency100-1000 Hz100-1000 Hz
    Discharge currentMax 380AMax 380A
    Excitation Stage Aperture13mm13mm
    Vacuum systemVacuum systemVacuum system
    Working power supply220V AC,50/60Hz,Protective grounded single-phase power supply220VAC,50/60Hz,Protective grounded single-phase power supply
    Instrument size720X560X370mm860x660x360mm
    Instrument weight65kg80kg

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    Packing & Delivery

    Desktop Full-spectrum Direct Reading Spectrometer Multi-element Analyzer Copper Aluminum Iron Zinc Magnesium

    FAQ

    1. who are we?
    We are based in Shanghai, China, start from 2017,sell to North America(20.00%),Western Europe(15.00%),South America(10.00%),Oceania(10.00%),Northern Europe(10.00%),Eastern Europe(10.00%),South Asia(5.00%),Southern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 5-10 people in our office.

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you buy from us?
    Differential Scanning Calorimeter, Thermogravimetric Analyzer, Differential Thermal Analyzer, Oxygen Bomb Calorimeter, Spot Cooler

    4. why should you buy from us not from other suppliers?
    We have 10 years of experience in design and development. The price preferential benefit There is a lot of goods in stock The service is good

    5. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,DDU,Express Delivery,DAF;
    Accepted Payment Currency:USD;
    Accepted Payment Type: T/T,Credit Card,Western Union;
    Language Spoken:English,Chinese
